USED USED GTO OEM CUMMINS QSX15 )8761) CAST ALUMINUM, FULL SUMP OIL PAN 3684708 SUMP LOCATION: FULL SUMP MATERIAL: CAST ALUMINUM HIGH OIL PAN CAPACITY: 83.3 L (22.0 GAL) LOW OIL PAN CAPACITY: 75.7 L (20.0 GAL) ENGINE CAPACITY: 90.8 L (24 GAL.) ANGULARITY LIMITS: 45 DEGREES FRONT DOWN 45 DEGREES REAR DOWN 45 DEGREES FUEL PUMP DOWN 45 DEGREES EXHAUST DOWN DRAIN LOCATION (M27 X 2 STRAIGHT THREAD O RING): SIDE

USED CUMMINS ISM M11 OIL PAN 4906835 30806B

USED USED GTO CUMMINS QSX15 (3961) ENGINE OIL PAN 4386810 SUMP LOCATION: FRONT MATERIAL: STAMPED STEEL HIGH OIL PAN CAPACITY: 45.4 L (12.0 GAL) LOW OIL PAN CAPACITY: 37.9 L (10.0 GAL) ENGINE CAPACITY: 53 L (13 GAL) ANGULARITY LIMITS: 45 DEGREES FRONT DOWN 33 DEGREES REAR DOWN 45 DEGREES FUEL PUMP DOWN 31 DEGREES EXHAUST DOWN DRAIN LOCATION (M27 X 2 STRAIGHT THREAD O RING): SIDE NO DRAIN PROVISION ON SHALLOW SUMP

USED USED GTO CUMMINS QSX15 (5428) ENGINE OIL PAN 4386810 SUMP LOCATION: FRONT MATERIAL: STAMPED STEEL HIGH OIL PAN CAPACITY: 45.4 L (12.0 GAL) LOW OIL PAN CAPACITY: 37.9 L (10.0 GAL) ENGINE CAPACITY: 53 L (13 GAL) ANGULARITY LIMITS: 45 DEGREES FRONT DOWN 33 DEGREES REAR DOWN 45 DEGREES FUEL PUMP DOWN 31 DEGREES EXHAUST DOWN DRAIN LOCATION (M27 X 2 STRAIGHT THREAD O RING): SIDE NO DRAIN PROVISION ON SHALLOW SUMP

USED USED GTO CUMMINS QSX15 (3961) ENGINE OIL PAN 4386810 SUMP LOCATION: FRONT MATERIAL: STAMPED STEEL HIGH OIL PAN CAPACITY: 45.4 L (12.0 GAL) LOW OIL PAN CAPACITY: 37.9 L (10.0 GAL) ENGINE CAPACITY: 53 L (13 GAL) ANGULARITY LIMITS: 45 DEGREES FRONT DOWN 33 DEGREES REAR DOWN 45 DEGREES FUEL PUMP DOWN 31 DEGREES EXHAUST DOWN DRAIN LOCATION (M27 X 2 STRAIGHT THREAD O RING): SIDE NO DRAIN PROVISION ON SHALLOW SUMP

USED USED TAKE OFF 3882733 OIL PAN

USED USED GTO OEM CUMMINS QSX15 (3961) ENGINE OIL PAN 4386810 OIL PAN SUMP LOCATION: FRONT MATERIAL: STAMPED STEEL HIGH OIL PAN CAPACITY: 45.4 L (12.0 GAL) LOW OIL PAN CAPACITY: 37.9 L (10.0 GAL) ENGINE CAPACITY: 53 L (13 GAL) ANGULARITY LIMITS: 45 DEGREES FRONT DOWN 33 DEGREES REAR DOWN 45 DEGREES FUEL PUMP DOWN 31 DEGREES EXHAUST DOWN DRAIN LOCATION (M27 X 2 STRAIGHT THREAD O RING): SIDE

USED USED GTO OEM CUMMINS X15 (4342) OIL PAN 4386821 OIL PAN SUMP LOCATION: FRONT MATERIAL: STEEL CONSTRUCTION: STAMPED SUMP CAPACITY: 11 GAL HIGH, 9 GAL LOW ANGULARITY LIMITS (GRAVITATIONAL HORIZONTAL): 38 DEGREES FRONT DOWN 22 DEGREES REAR DOWN 30 DEGREES FUEL PUMP DOWN 30 DEGREES EXHAUST DOWN UNIQUE CHARACTERISTICS: STUDS ON OIL PAN FLANGE LOCATED AT #2, #5, #28 AND #32 MOUNTING HOLES ON EXHAUST SIDE AND AT #11, #12, #15, #16, #18, #19, #22 AND #23 MOUNTING HOLES ON FUEL PUMP SIDE OF ENGINE REFER TO THE NEW ENGINE BUILD STANDARD FOR D10 HOLE LOCATIONS IN OIL PAN. AEB 46.05 MAY ALSO BE CONSULTED. MAXIMUM WEIGHT LIMIT ON ANY SINGLE STUD IS SEVEN (7) POUNDS. POWER ANGLE: NOT TO EXCEED 5 DEG. AEB 20.17 MIGHT BE CONSULTED FOR MORE DETAILS REGARDING MAX

USED USED NTO OEM CUMMINS ISX12G (3647) ENGINE OIL PAN 4975061 OIL PAN SUMP LOCATION: FRONT MATERIAL: STAMPED STEEL HIGH OIL PAN CAPACITY: 11 GALLONS LOW OIL PAN CAPACITY: 9 GALLONS FRONT DOWN ANGULARITY: 45 DEGREES REAR DOWN ANGULARITY: 45 DEGREES FUEL PUMP DOWN ANGULARITY: 45 DEGREES EXHAUST DOWN ANGULARITY: 45 DEGREES DRAIN LOCATION (M27 X 2 STOR): BOTTOM AND SIDE ISOLATED: NO OIL HEATER BOSS (M14 X 1.5 STOR): EITHER SIDE OIL TEMPERATURE BOSS (M14 X 1.5 STOR): EITHER SIDE RUST INHIBITOR REQUIRED: NO UNIQUE CHARACTERISTICS: STUDS ON OIL PAN STUDS ON OIL PAN FLANGE LOCATED AT #2, #13, #14, #19, #21 AND #25 REFER TO THE D0K NEBS FOR HOLE LOCATIONS IN OIL PAN. MAXIMUM WEIGHT LIMIT ON ANY SINGLE STUD: 5 LBS

NEW 48 QUART STEEL OIL PAN CUMMINS ISX FRONT/REAR SUMP

NEW CUMMINS M11 REAR/WET SUMP STEEL OIL PAN 38 QUARTS 32 MOUNTING HOLES OIL LEVER SENSOR PORT & PICK-UP TUBE INCLUDED

USED USED GTO CUMMINS QSX15 (3961) ENGINE OIL PAN 4386810 SUMP LOCATION: FRONT MATERIAL: STAMPED STEEL HIGH OIL PAN CAPACITY: 45.4 L (12.0 GAL) LOW OIL PAN CAPACITY: 37.9 L (10.0 GAL) ENGINE CAPACITY: 53 L (13 GAL) ANGULARITY LIMITS: 45 DEGREES FRONT DOWN 33 DEGREES REAR DOWN 45 DEGREES FUEL PUMP DOWN 31 DEGREES EXHAUST DOWN DRAIN LOCATION (M27 X 2 STRAIGHT THREAD O RING): SIDE NO DRAIN PROVISION ON SHALLOW SUMP

NEW STEEL OIL PAN CUMMINS BIG CAM III & IV, N14 STEEL REAR WET SUMP OIL PAN WITH INTERNAL SUCTION TUBE AND PLUGS 44 QUARTS DRAIN PLUG 1-18 36 MOUNTING HOLES OIL LEVEL SENSOR PORT 5 TOTAL PORTS 47"L X 15.50"W X 11.50"H NON-BAFFLED

USED S18E0035 - Used Oil Pan from a 2005 from a 2005 Kenworth W900 Casting# - 3680530 Supercedes to 4952540 Material - Steel Sump - Rear/Front

NEW 3046951 OR 3046947 STEEL WET FRONT SUMP OIL PAN ASSEMBLY KIT CUMMINS BIG CAM III/IV AND N14 INTERNAL SUCTION TUBE 44 QUART DRAIN PLUG INCLUDED 36 MOUNTING HOLES 4 PORTS

NEW STEEL REAR WET SUMP OIL PAN CUMMINS ISM/L10/M11 NOT BAFFLED 38 QUART 4 TOTAL PORTS DRAIN PLUG AND GASKET INCLUDED 32 MOUNTING HOLES

NEW 10.5 GALLON ALUMINUM OIL PAN BLEM - STRIPPED THREADS

NEW STEEL OIL PAN CUMMINS BIG CAM III & IV, N14 STEEL REAR WET SUMP OIL PAN WITH INTERNAL SUCTION TUBE AND PLUGS 44 QUARTS DRAIN PLUG 1-18 36 MOUNTING HOLES OIL LEVEL SENSOR PORT 5 TOTAL PORTS 47"L X 15.50"W X 11.50"H NON-BAFFLED

NEW BLEM - STRIPPED THREADS PAN,OIL REPLACES --> 3266185

NEW AFTERMARKET New Aftermarket M11 Oil Pan

NEW AFTERMARKET New Aftermarket M11 Oil Pan

NEW BLEM - STRIPPED THREADS FULL SUMP 21 GAL WITH P/U TUBE # 3679714 SAME AS 3680894, 3103453

NEW PAN,OIL W/ P/U TUBE REPLACES --> 3266185

USED FRONT SUMP 3958209

NEW BLEM - SCRATCH & DENT
