USED USED NTO OEM CUMMINS QSX15 (3869) CAST IRON FLYWHEEL HOUSING 3102463 FLYWHEEL HOUSING SAE SIZE OR TYPE: 1 FLYWHEEL HOUSING MATERIAL: CAST IRON ENGINE MOUNT TYPE: LOW VERTICAL PAD TRANSMISSION MOUNTING HOLE NOMENCLATURE: SAE STARTING MOTOR MOUNTING SCREWS: SAE STARTER CENTER DISTANCE: 275.6 MM (10.85 IN) CLUTCH TYPE PROVISION: DRY SENSOR MOUNTING HOLE NOMENCLATURE: QUAD 1, 5/8 - 18 AND QUAD 4, 3/4 - 16 REAR GEAR DRIVE: YES TRANSMISSION MTG FACE TO RFOB: 309.3 MM (12.2 IN) STARTER LOCATION: 2ND AND 3RD QUADRANT SENSOR MOUNTING HOLE COUNT: TWO UNIQUE CHARACTERISTICS: HOUSING DESIGNED TO PROVIDE REAR ENGINE POWER TAKE OFF WHEN USED IN COMBINATION WITH DR OPTIONS. LIMITED TO 500 LBS. RADIAL LOAD

USED USED GTO OEM CUMMINS QSX15 (5428) FLYWHEEL HOUSING / ENGINE SUPPORT 5537023 FLYWHEEL HOUSING FLYWHEEL HOUSING SAE SIZE OR TYPE: 1 FLYWHEEL HOUSING MATERIAL: DUCTILE IRON ENGINE MOUNT TYPE: FORWARD-REACHING ANGLED ARMS ENGINE MOUNT BOLT SIZE: 22 MM ENGINE MOUNT LOCATION FROM RFOB: 143.7 MM AXIAL 24.3 MM VERT. 424.0 MM LATERAL STARTER MOTOR MOUNTING: SAE TYPE 1 STARTER BORE DIAMETER: 92.15 MM (3.63 IN) STARTING MOTOR MOUNTING SCREWS: CUSTOMER SUPPLIED (METRIC) STARTER CENTER DISTANCE: 265.1 MM (10.44 IN) CLUTCH TYPE PROVISION: NONE SENSOR MOUNTING HOLE NOMENCLATURE: N/A REAR GEAR DRIVE: NO TRANSMISSION MTG FACE TO RFOB: N/A STARTER LOCATION: 3RD QUADRANT SENSOR MOUNTING HOLE COUNT: NONE CONTAINS TWO M16 TAPPED HOLES AT THE TOP AND TWO M10 TAPPED HOLES AT THE BOTTOM FOR OEM USE CONTAINS TWO HOLES FOR DOWEL PINS FOR OEM USE

USED USED GTO OEM CUMMINS QSX15 (3961) FLYWHEEL HOUSING / ENGINE SUPPORT 3691004 FLYWHEEL HOUSING SAE SIZE OR TYPE: 1 FLYWHEEL HOUSING MATERIAL: DUCTILE IRON ENGINE MOUNT TYPE: FORWARD-REACHING ANGLED ARMS ENGINE MOUNT BOLT SIZE: 22 MM ENGINE MOUNT LOCATION FROM RFOB: 143.7 MM AXIAL 24.3 MM VERT. 424.0 MM LATERAL STARTER MOTOR MOUNTING: SAE TYPE 1 STARTER BORE DIAMETER: 92.15 MM (3.63 IN) STARTING MOTOR MOUNTING SCREWS: CUSTOMER SUPPLIED (METRIC) STARTER CENTER DISTANCE: 265.1 MM (10.44 IN) CLUTCH TYPE PROVISION: NONE SENSOR MOUNTING HOLE NOMENCLATURE: N/A REAR GEAR DRIVE: NO TRANSMISSION MTG FACE TO RFOB: N/A STARTER LOCATION: 3RD QUADRANT SENSOR MOUNTING HOLE COUNT: NONE CONTAINS M16 TAPPED HOLES FOR OEM USE

USED USED GTO OEM CUMMINS QSX15 (8760) CAST IRON FLYWHEEL HOUSING 4026677 HAS SOME RUST ALL AROUND THE OUTSIDE

USED USED GTO OEM CUMMINS QSX15 (8760) ALUMINUM FLYWHEEL HOUSING 3102196 / 3103584 Flywheel Housing SAE Size: No. 1 Flywheel Housing Material: Aluminum Engine Mount Type: 10 Deg. Pads. Transmission Mounting Hole Nomenclature: English (in) Starter Motor Mounting Screws: English (in) Starter Center Distance: 10.437 Clutch Type Provision: Dry Tachometer Sensor Mounting Hole Count: One

USED USED GTO OEM CUMMINS QSX15 (2825) CAST IRON FLYWHEEL HOUSING 4026662

USED USED GTO OEM CUMMINS QSX15 (8761) CAST IRON FLYWHEEL HOUSING INDUSTRIAL USE, DUAL STARTER, SAE 1 4026662

USED Industrial, SAE1, Cast Iron, 12 bolt, dual starter positions, dry flywheel housing.

USED INDUSTRIAL, SAE 1, 12 BOLT, CAST IRON, DUAL STARTER POSITIONS, DRY FLYWHEEL HOUSING

ISX / QSX ENGINE REAR BELL FLYWHEEL HOUSING 50245 4026662 / 1772 *** Any other questions, please call us! Be sure to check out the rest of our store. We have a huge selection of discounted new and used truck parts. *** Normal Business hours are Monday - Friday 8:30 AM to 4:30 PM CST ***

USED USED GTO OEM CUMMINS QSX15 (3961) FLYWHEEL HOUSING / ENGINE SUPPORT 3691004

USED USED NTO OEM CUMMINS QSX15 CAST IRON FLYWHEEL HOUSING 4026662

USED Industrial, SAE0, Cast Iron, 12 bolt, dual starter positions, dry flywheel housing.
